The raised bed former BGR is suitable for making raised beds with T-tape and film for growing strawberries.

General Specifications

Capacity 5000 metres per hour

Optional

  • Additional T-tape layer
  • Marker stitch wheel
  • Steering disc for a more stable machine
  • Other model conical roller

Common Configurations

Model Number of raised beds width of ridge Bed height Linkage Weight Power requirement Hydraulics
BGR\180 1 650 mm 200 mm 3-Point linkage cat. 2 1000 kg 70 hp 1 double-acting pilot valve, 20 l/min & 1 (single-acting) pilot valve + return, 40 l/min
BGR\240 2 450 mm 200 mm 3-Point linkage cat. 2 1600 kg 90 hp 1 double-acting pilot valve, 20 l/min & 1 (single-acting) pilot valve + return, 40 l/min
